R901048604 — Pump Control System SYDFEC-2X/071R-PRA12KD5-0479-A2A0FLX
PUMP CONTROL SYSTEM
SYDFEC-2X/071R-PRA12KD5-0479-A2A0FLX
Mărime 71 cm³ · Presiune max. de lucru 280 bar · Debit max. 156 l/min
Specificații tehnice
| Connectivity | Digital |
| Sens de rotație | Clockwise rotation |
| Displacement type | variable |
| Electric connection description | Connector, 12-pole (11 + PE) according to EN 175201-804 |
| Electrical connector | Connector, 12-pole (11 + PE) |
| Greutate brută | 42.5 kg |
| Hydraulic fluid | HLP |
| Debit max. | 156 l/min |
| Mounting flange | ISO 2-hole |
| Greutate netă | 42.5 kg |
| Presiune max. de lucru | 280 bar |
| Seals | FKM |
| Shaft end | Geared shaft (R) |
| Mărime | 71 cm³ |
| Supply voltage | 24 VDC |
| Through drive | with |
| Greutate | 42.5 kg |
Documentație tehnică
Piese de schimb — vedere explodată
| Poz. | Cod material | Denumire | Cant. |
|---|---|---|---|
| 20 | R900720202 | DISTRIBUITOR PROPORŢIONAL | 1 |
| 40 | R901342038 | TRADUCTOR DE PRESIUNE | 1 |
| 998 | R900868651 | SENS DE DEZLOCUIRE | 1 |
| 999 | R961000356 | SET DE GARNITURI | 1 |
